Slijtvast staal volgens datasheet van de fabrikant
Soorten | Diktes (mm) | Breedtes (mm) | Lengtes (mm) | Inspectiecertificaten volgens DIN EN 10204 |
---|---|---|---|---|
300 HB | 8 – 60 | 2.000 – 3.000 | tot 12.000 | 3.1 |
400 HB | 3 – 150 | 1.500 – 3.000 | tot 12.000 | 3.1 |
400 HB W/CR | 6 – 60 | 2.000 – 3.000 | tot 12.000 | 3.1 |
450 HB | 4 – 100 | 1.500 – 3.500 | tot 12.000 | 3.1 |
500 HB | 3 – 100 | 1.500 – 3.500 | tot 12.000 | 3.1 |
600 HB | 8 – 40 | 2.000 – 2.500 | tot 6.000 | 3.1 |
X120Mn12 | 1,5 – 60 | 1.000 – 2.500 | tot 8.000 | 3.1 |
27MnB5 | 3 – 60 | 1.500 – 3.000 | tot 12.000 | 3.1, 2.2 |
30MnB5 | 3 – 60 | 1.500 – 3.000 | tot 12.000 | 3.1, 2.2 |
